Data Memory (DM) Allocation Section 7-4
Note 1. These words are used to notify the CPU Unit of the Simple Communica-
tions Unit’s status.
2. The functions in parentheses are for CompoWay/F communications.
Simple Communications Unit Control (Offset: +0)
+5 Communications control for Units 16 to 23
+6 Communications control for Units 24 to 31
+7 Unit 0 communications type
+8 Starting address of Unit 0 read data area
(Starting address of Unit 0 read variable type area*
2
)
+9 Starting address of Unit 0 write data area
(Starting address of Unit 0 write variable type area*
2
)
+10 Unit 1 communications type
+11 Starting address of Unit 1 read data area
(Starting address of Unit 1 read variable type area*
2
)
+12 Starting address of Unit 1 write data area
(Starting address of Unit 1 write variable type area*
2
)
:
:
:
:
+100 Unit 31 communications type
+101 Starting address of Unit 31 read data area
(Starting address of Unit 31 read variable type area*
2
)
+102 Starting address of Unit 31 write data area
(Starting address of Unit 31 write variable type area*
2
)
Offset Function
Bits Setting Range Function
0 to 3
(Digit 16
0
)
RUN/Stop 1: RUN
0: Stop
If this digit is set to 1 after the power is turned ON, the Simple Communica-
tions Unit will start communications with components and the CPU Unit. (If
a fatal error has occurred, the Unit will not start communications with com-
ponents even if this digit is set to 1.)
The Simple Communications Unit will not communicate with components if
this digit is set to 0.
4 to 7
(Digit 16
1
)
Communications
timeout
0 to 9
(BCD)
Sets the response monitoring time for access from the Simple Communica-
tions to connected components. The timeout time is set in multiples of
500 ms ((Set value + 1) × 500 ms). This setting is usually set to 0, which
sets a response monitoring time of 500 ms.
8 to 15
(Digits 16
2
and 16
3
)
Number of con-
nected components
00 to 32
(BCD)
Specifies the number of components connected to the Simple Communica-
tions Unit. The Simple Communications Unit will not communicate with
components if the number of connected components is set to 0.
