Omron CPM2C User Manual

279
Dimensions Appendix B
Expansion
I/O Units
Ter mi n al
Blocks
(Relay Out-
puts)
10 I/O
points
CPM2C-10EDR 200 g max.
20 I/O
points
CPM2C-20EDR 200 g max.
8 output
points
CPM2C-8ER 200 g max.
Fujitsu-
compatible
Connectors
24 I/O
points
CPM2C-24EDTC 200 g max.
CPM2C-24EDT1C 200 g max.
32 I/O
points
CPM2C-32EDTC 200 g max.
CPM2C-32EDT1C 200 g max.
8 input
points
CPM2C-8EDC 150 g max.
16 input
points
CPM2C-16EDC 150 g max.
8 output
points
CPM2C-8ETC 150 g max.
CPM2C-8ET1C 150 g max.
16 output
points
CPM2C-16ETC 150 g max.
CPM2C-16ET1C 150 g max.
MIL
Connectors
24 I/O
points
CPM2C-24EDTM 200 g max.
CPM2C-24EDT1M 200 g max.
32 I/O
points
CPM2C-32EDTM 200 g max.
CPM2C-32EDT1M 200 g max.
8 input
points
CPM2C-8EDM 150 g max.
16 input
points
CPM2C-16EDM 150 g max.
8 output
points
CPM2C-8ETM 150 g max.
CPM2C-8ET1M 150 g max.
16 output
points
CPM2C-16ETM 150 g max.
CPM2C-16ET1M 150 g max.
Power Supply Unit CPM2C-PA201 250 g max.
Expansion
I/O Units
Analog I/O Unit CPM2C-MAD11 200 g max.
Temperature Sensor Unit CPM2C-TS001 200 g max.
CPM2C-TS101 200 g max.
CompoBus/S I/O Link Unit CPM2C-SRT21 150 g max.
Simple Communications
Unit
CPM2C-CIF21 150 g max.
Peripheral/RS-232C Adapter Unit CPM2C-CIF01-V1 150 g max.
RS-422/RS-232C Adapter Unit CPM2C-CIF11 150 g max.
Unit Model number Weight
