3 - 115
3 Specifications
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
3-6 Servo Relay Unit and Cable Specifications
3
3-6-3 Position Control Unit Relay Unit Cable Specifications
Below are the specifications of the cable that connects a Position Control Unit (Model: CJ1W-NC113)
with a Servo Relay Unit (Model: XW2B-20J6-1B).
 Cable types
 Connection configuration and external dimensions
 Wiring
Position Control Unit Cables (XW2Z-J-A14)
Model Length (L) Outer diameter of sheath Weight
XW2Z-050J-A14 50 cm 10.0 dia. Approx. 0.1 kg
XW2Z-100J-A14 1 m Approx. 0.2 kg
L6
38
t=11
500
CJ1W-NC113 XW2B-20J6-1B
20J6
-
1B
CJ1W
-
NC113
Position Control Unit side Servo Relay Unit side
No.
A1
A2
A8
A6
A9
A20
A11
A14
A12
A17
A19
A18
A15
A16
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
26
24
25
Cable: AWG28×4P+AWG28×10C
Position Control Unit side Servo Relay Unit side
Crimp terminal
