Omron G5 Series User Manual

4 - 27
4 System Design
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
4-3 Wiring Conforming to EMC Directives
4
4-3-2 Selecting Connection Components
• Select a leakage breaker for high frequencies and surge resistance.
• When selecting leakage breakers, remember to add the leakage current from devices other than the
motor, such as devices using a switching power supply, noise filters, inverters, and so on.
To prevent malfunction due to inrush current, we recommend using a leakage breaker of 10 times the
total of all current values.
• The leakage breaker is activated at 50% of the rated current. Select a leakage breaker with
approximately twice the capacity.
• For details on leakage breakers selection method, refer to the manufacturer’s catalog.
• Because switching takes place inside the Servo Drives, high-frequency current leaks from the SW
elements of the Servo Drive, the armature of the motor, and the cables.
High-frequency and surge-resistant leakage breakers can prevent operation with high-frequency
leakage current because they do not detect high-frequency current.
When using a general leakage breaker, use three times the total of the leakage current given in the
following table as a reference value.
Note These values vary greatly depending on the installation conditions of the motor power cable and the
measurement conditions. Use the values for reference only.
Leakage Breaker
Servo Drive model Input power supply
Leakage current
(Cable: 3 m)
Increase per 10 m of cable
R88D-KP01H Single-phase 200 V 0.83 mA 0.23 mA
3-phase 200 V 1.03 mA
R88D-KP02H Single-phase 200 V 0.84 mA
3-phase 200 V 1.02 mA
R88D-KP04H Single-phase 200 V 0.96 mA 0.3 mA
3-phase 200 V 1.27 mA
R88D-KP08H Single-phase 200 V 1.01 mA 1.1 mA
3-phase 200 V 1.39 mA
R88D-KP10H Single-phase 200 V 0.88 mA 0.93 mA
3-phase 200 V 1.14 mA
R88D-KP15H Single-phase 200 V 0.96 mA
3-phase 200 V 1.18 mA
R88D-KP20H 3-phase 200 V 1.53 mA 1.23 mA
R88D-KP30H 3-phase 200 V 1.52 mA
R88D-KP50H 3-phase 200 V 1.39 mA

Omron G5 Series Specifications

General

Feedback	Incremental Encoder, Absolute Encoder
Communication	EtherCAT
Safety Function	STO (Safe Torque Off)
Protection Functions	Overvoltage, Undervoltage, Overcurrent
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
