8 Operation
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
8-4 Mode Setting
8
8-4-2 Monitor Mode
Do not set.
Total Encoder Pulses
Total Command Pulses
Reserved
Lower (L)
Higher (H)
Total Encoder Pulses [Encoder Pulse]
Press to switch Lower (L) and Higher (H).
Total Command Pulses [Command Pulse]
Lower (L)
Higher (H)
Press to switch Lower (L) and Higher (H).
