Omron WS02-SIMC1-E - V1.9 REV 02-2009 User Manual

I/O Memory Allocation Section 9-3
226
Address CS/CJ-series PLC CX-Simulator
Words Bits
Name
Function Settings Function Settings
A40700
to
A40712
Too Many
I/O Points,
Details
The 6 possible causes of the Too
Many I/O Points Error are listed
below. The 3-digit binary value in
A40713 to A40715 indicates the
cause of the error (values 0 to 5
correspond to causes 1 to 6,
below).
The 13-bit binary value in A40700
to A40712 indicates the details:
the excessive value or the dupli-
cated unit number.
CPU Unit operation will stop and
the ERR/ALM indicator on the
front of the CPU Unit will light.
1) The number of I/O points will
be written here when the total
number of I/O points set in the
I/O Table (excluding Slave
Racks) exceed the maximum
allowed for the CPU Unit.
2) The number of interrupt inputs
will be written here when there
are more than 32 interrupt in-
puts.
3) The unit number of the Slave
Unit will be written here when
a unit number is duplicated or
the number of I/O points on a
C500 Slave Unit exceeds 320.
4) The unit number of the I/O
Terminal (excluding Slave
Racks) will be written here
when a unit number is dupli-
cated
5) The unit number of the Master
Unit will be written here when
a unit number is duplicated or
the unit number is outside of
the allowed setting range.
6) The number of Racks will be
written here when the number
of Expansion I/O Racks ex-
ceeds the maximum.
0000 to
1FFF
hexadeci-
mal
Not used.
A407
A40713
to
A40715
Too Many
I/O Points,
Cause
The 3-digit binary value of these
bits indicates the cause of the
Too Many I/O Points Error and
shows the meaning of the value
written to bits A40700 to A40712.
Values of 000 to 101 (0 to 5)
correspond to causes 1 through 6
described in “Too Many I/O
Points, Cause 1,” above.
Not used.
