Connecting Cluster Cables
FIGURE 50
ZS5-4 Controller Cluster Cabling
The following figure shows cluster cabling between two ZS5-2 controllers.
FIGURE 51
ZS5-2 Controller Cluster Cabling
ZS4-4 Cluster Cabling
Three Category 5 Ethernet cables are provided. Each cable is 1 meter in length. Connect the
cables in the same way as described for ZS5-x controllers.
The following figure shows cluster cabling between two ZS4-4 controllers.
Cabling the Appliance 223
