Controller Cluster I/O Ports
FIGURE 54
ZS9-2 Controller Cluster I/O Ports
Figure Legend
1 Ethernet Activity LED 2 Ethernet Link Status
LED
3 Port 3 (Ethernet I/O) 4 Port 2 (Ethernet I/O)
5 Port 1 (Cluster Link) 6 Port 0 (Cluster Link)
The following diagram illustrates the cluster serial and Ethernet ports for ZS7-2, ZS5-4, ZS5-2,
ZS4-4, ZS3-4, and 7x20 controllers.
226 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021
