Overview of Disk Shelves
FIGURE 6
DE3-24C Rear Panel
Figure Legend
1 Power supply filler panel, slot 4 2 I/O Module 1 3 I/O Module filler panel
4 Power supply with fan module 2 5 Power supply filler panel, slot 2 6 I/O Module filler panel
7 I/O Module 0 8 Power supply with fan module 1
Note - It is especially important that power supplies and their filler panels are in the correct
slots.
Installation Prerequisites and Hardware Overviews 31
