Overview of Disk Shelves
FIGURE 7
DE3 I/O Module Indicators
Figure Legend
1 For Oracle service only 2 Locate indicator 3 Service required indicator
4 OK indicator 5 SAS-3 Port 0 6 SAS-3 Port 1
7 SAS-3 Port 2 8 SAS-3 Port 3 9 Host port service required indicator
10 Host port activity indicator 11 Power/Activity indicator 12 I/O Module service required
indicator
13 Ready-to-remove indicator 14 For Oracle service only
The DE3-24C and DE3-24P disk shelves use the same I/O Module.
32 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021
