VS 2001
Technical Handbook
Accessories
P/N: 779-0373/02
Revision 02
Marconi Proprietary information
Page 115
Fig. 7.17: Call test
Dial the sequence to call the reference
hand-held terminal.
CALL TEST
The call has been
correctly completed?
Go to RX
TEST
Replace the Radio equipment
on test with the reference one.
The Radio equipment
on test is faulty.
The problem is caused by the reference
system. In particular the hand-held
terminal and the BS must be checked.
Dial the sequence to call the reference
equipment.
The call has been
correctly completed?
Replace the control panel with
the reference one.
The control panel is
faulty.
The call has been
correctly
completed?
YES
NO
YES
NO
YES
NO
To Next Page
