1.8 TECHNICAL CHARACTERISTICS
The VS 2001 equipment main technical characteristics are shown in Tab. 1.2.
Tab. 1.2: Technical characteristics
Parameters Type/Value
Dimensions
VS 2001 Radio Unit 202,4 x 186,4 x 58,4 mm
FPG1/A Control Panel 210 x 70,3 x 66,5 mm
Electrical characteristics
Air interface signalling EN 300-392-2
Power class 2 (10 W)
TX frequency band (Trunked Mode) VS 2001-400:
VS 2001-430:
VS 2001-470:
(380÷390) MHz
(410÷420) MHz
(450÷460) MHz
RX frequency band (Trunked Mode) VS 2001-400:
VS 2001-430:
VS 2001-470:
(390÷400) MHz
(420÷430) MHz
(460÷470) MHz
TX frequency band (Direct Mode) VS 2001-400:
VS 2001-430:
VS 2001-470:
(380÷400) MHz
(410÷430) MHz
(450÷470) MHz or
(445,2÷445,3) MHz
RX frequency band (Direct Mode) VS 2001-400:
VS 2001-430:
VS 2001-470:
(380÷400) MHz
(410÷430) MHz
(450÷470) MHz or
(445,2÷445,3) MHz
Automatic power control Compliant EN 300 392-2
Carrier spacing 25 kHz
Receiver class EN 300 392-2 class A + B
RF architecture Half-duplex
Audio power 8 W, on 4 Ohm
Supply source Regulated Lead-Acid Battery
Nominal supply voltage Negative grounded: +13.8 VDC
Range: +10.8VDC to +15.6VDC
Power consumption (average on frame,
4 timeslots)
Stand by: < 1.3 A
Receiving mode: < 3 A
Transmitting mode: < 8 A
EMC specifications EN 301 489-18
Class EN 60950 class II
Installation category IEC 664 class I
