OTE VS 2001 - Fig. 7.19: Test on Quality of the Received LF

VS 2001
Technical Handbook
Accessories
P/N: 779-0373/02
Revision 02
Marconi Proprietary information
Page 117
Fig. 7.19: Test on quality of the received LF
Talk from the hand-held terminal to
Radio equipment.
TEST ON QUALITY OF
THE RECEIVED LF
Does the Radio equipment
clearly receive the LF
from the hand-held
terminal?
Replace the Radio equipment
on test with the reference one.
The problem is caused by the
system. In particular the
connection and the loudspeaker
must be checked.
Go to TX TEST
The Radio equipment on
test is faulty.
Does the Radio equipment
clearly receive the LF
from the hand-held
terminal?
YES
NO
YES
NO
