VS 2001
Technical Handbook
Accessories
P/N: 779-0373/02
Revision 02
Marconi Proprietary information
Page 123
8. CORRECTIVE MAINTENANCE
The information necessary to carry out the replacement operations relatively to the
corrective maintenance on the VS 2001 radio equipment is gathered in this
section.
8.1 INTRODUCTION
The corrective maintenance operations required by the equipment taken into
consideration are substantially limited to the replacement of replaceable parts.
The tools and the consumable materials needed to carry out the maintenance
activities are listed, when required, together with the procedures to be followed to
carry out the operations. All the information is gathered in the proper corrective
maintenance (CM) forms.
8.2 COLLECTION OF CORRECTIVE MAINTENANCE FORMS
In this chapter all the CM forms describing the relative corrective maintenance
operations to be carried out on the VS 2001 radio terminal are gathered. All the
forms are sequentially numbered.
The operations which can be carried out at the I and II maintenance level, without
the intervention of the OTE assistance centre, are summarised in Tab. 8.1.
Tab. 8.1: Summary of the corrective maintenance operations
Fuses replacement VS 2001 CM-01
Frontal panel replacement VS 2001 CM-02
VS 2001 antenna replacement VS 2001 CM-03
VS 2001 radio equipment replacement VS 2001 CM-04
