Fig. 7.18: RX test
Talk from the hand-held terminal
towards the radio equipment.
RX TEST
Set the MAX volume level
on the radio under test
Does the radio equipment
receive the LF
transmitted from the
reference hand-held
terminal?
Replace the Radio equipment
to be tested with the reference one.
The problem is caused by the
system. In particular the
connection must be checked.
Go to the received
LF quality test.
Does the Radio equipment
receive the LF
transmitted by the hand-
held?
The Radio equipment
on test is faulty.
YES
NO
YES
NO
