Tab. 1.2: Technical characteristics (Cont’d)
Parameters Type/Value
Environmental characteristics (Radio Unit module)
Operative temperature -20° to +55°C
Storage temperature -40° to +85°C
Relative humidity 10 to 95% at 50°C non condensing
Cold test ETS 300 019-1-5 class 5.2 (within the
operative temperature range)
Dry hot test ETS 300 019-1-5 class 5.2 (within the
operative temperature range)
Air temperature change test ETS 300 019-1-5 class 5.2
Damp heat cyclic test ETS 300 019-1-5 class 5.2
Protection to dust and water IP54
Shock and vibrations ETS 300 019 1-5 IEC class 5M3
Environmental characteristics (Front Panel module)
Operating temperature range -20 to + 60°C
Storage -40 to + 85°C
Relative humidity 10 to 95% at 55°C
Protection to dust IP54
Shock and vibrations ETS 300 019 1-5 IEC class 5M3
Transmitter characteristics
Modulation
π/4 DQPSK
Maximum power in antenna 10W (Tetra Power Class 2)
Power of undesired output in non active
transmission state
In compliance with EN 300 392-2
Adjacent channel power due to modulation In compliance with EN 300 392-2
Adjacent channel power due to commutation
transistors.
In compliance with EN 300 392-2
Undesired emissions far from the carrier In compliance with EN 300 392-2
Receiver characteristics
Sensitivity In compliance with EN 300 392-2
Rejection of co-channel In compliance with EN 300 392-2
Blocking characteristic In compliance with EN 300 392-2
Rejection of spurious response In compliance with EN 300 392-2
Rejection of inter-modulation response In compliance with EN 300 392-2
Conducted emission undesired In compliance with EN 300 392-2
Irradiated emission undesired In compliance with EN 300 392-2
