The Base Band card is housed on one side of the Radio Unit module, while the
other two cards on the reverse side (see Fig. 2.3 and Fig. 2.4).
Fig. 2.3: View from the Base Band card side
Fig. 2.4: View from the R/T and P.A. cards side
BASEBAND CARD
J04
P01
J02
P.A. CARD
R/T CARD
J18
J06
J15
ANTENNA
