VS 2001

Technical Handbook

Accessories

P/N: 779-0373/02

Revision 02

Marconi Proprietary information

Page 127

Equipment

VS 2001 Radio Equipment (vehicle configuration)

Operation

FPG1/A replacement

Required tools

Screw-driver

Consumable materials

-FPG1/A

Form number

CM-02A

Page

1/2

Periodicit

Maintenance level

Not a

licable

PROCEDURE

Read all the safety recommendations before proceeding.

• When the car engine is off, switch OFF the equipment by means the proper button of the

FPG1/A front panel.

• Disconnect the positive terminal of the power supply cable from the car battery.

• Unscrew the four fixing screws (1, Fig. 1) of the FPG1/A control panel and disconnect it

from the bracket.
