Ambient temperature -40 °C to +65 °C.
3.1 Transportation
The B500/B500-S power wheelchair must be properly
fastened to the transportation vehicle in order to secure it against shifting, e.g. with tensioning straps.
NOTICE
The maximum net weight of the B500/B500-S power wheelchair is 95 kg.
Hoisting and transportation devices used for transportation must have a sufcient capacity.
Secure the B500/B500-S power wheelchair inside the transportation vehicle, e.g. using tension-
ing straps. In order to do so, use the eyebolts at the front and back of the power wheelchair and
the dened mounting points in the transportation vehicle.
Before transporting the power wheelchair, switch off the control unit and engage the wheel lock.
You can reduce the size of the power wheelchair for transportation by folding down the back
rest and removing the side panels and footrests.
1 Eyebolts, rear
2 Eyebolts, front
