70
1. Remove the headrest.
2. Guide the metal rods of the headrest through the two loops on the control panel holder.
3. Reattach the headrest to the seat.
4. Adjust the width of the holder with the two set screws.
❒ Philips screwdriver
1. Loosen the four Phillips screws on the holder.
2. Remove the control panel and replace if required.
Properly reassemble all components upon completion of the work.
The control panel holder for the B500/B500-S power wheelchair is clamped to the underside
of the arm rest with an iron rail.
❒ Remove the side panel.
❒ Remove and set aside the control panel.
❒ Allen wrench, size 3
1. Remove the side panel from the holder.
2. Loosen the three set screws.
3. Change the position of the control panel holder, or remove the control panel holder and re-
place if required.
