68
1. Loosen the hexagon nut.
2. Remove the oscillating crank and replace if required.
Properly reassemble all components upon completion of the work.
When attaching the motors to the oscillating cranks, be sure to tighten the bottom
screws rst.
6.19 Accessories
❒ Allen wrench, size 6
1. Slide off the top of the joystick.
2. Slide an accessory such as the fork for tetraplegics, golf ball, stick etc. onto the metal pin.
3. Mount the accessory by tightening the set screw.
