53
(Option)
The seat bottom of the Recaro® seat modules is attached and removed in the same manner as
the complete Recaro® seat. The modular back rest is hooked into the seat bottom. Two corre-
sponding adapters are found on the seat bottom.
❒ Flat screwdriver
1. Attach the safety plate to the front adapter.
2. Hook the back rest onto the seat bottom.
3. Attach the front locking mechanism to the rear adapter.
Properly reassemble all components upon completion of the work.
6.11 Seating System Options
(Option)
Abductors are available as an option, and are attached to the front cross brace of the seat
frame with an adapter.
❒ Hand drill
❒ Drill bit, size 6
❒ Allen wrench, size 4
❒ Open-end or combination wrench, size 10
