(Option, B500 Only)
❒ Allen wrench, size 2
❒ Pin punch
1. Slide the spring onto the thin end of the bolt and insert both into the bore in the frame from
below.
2. Slide the set screw onto the locking lever and tighten.
(Option)
When installing the steering caster, ensure that the steering caster and drive wheel are aligned.
The splash guard for the steering caster is attached to the caster fork.
❒ Removing the steering caster
❒ Allen wrench, size 3
1. Hold the splash guard up against the caster fork so that the mounting holes line up.
2. Insert two Allen head screws through the holes from the inside to the outside and then
tighten.
