48
NOTICE
Take note of the cables attached to the seat frame with cable ties. Carefully
cut the cable ties with side-cutting pliers or a knife. Ensure that you do not damage the cables during
this process!
❒ Remove the side panels.
❒ Allen wrench, size 5
❒ Open-end or combination wrench, size 13
1. Loosen all cables connected to the seat frame by cable ties.
2. Loosen the two Allen head screws on the front seat brackets.
3. Loosen the two Allen head screws on the rear seat brackets.
4. Remove the seat frame and replace if required.
Properly reassemble all components upon completion of the work.
Only standard seats have a seat plate.
1. Remove the seat cushion.
2. Unlock the back rest and fold it forward.
3. Pull the seat plate up with a somewhat more forceful tug and replace it if required.
Properly reassemble all components upon completion of the work.
