51
1 Side panel attachment device
(Option)
The optional contour seat is attached to the seat plate with hook and loop straps. You can mount
the contour seat on the frame of the standard seat.
❒ Allen wrench, size 3
1. Set the seat bottom with hook and loop straps onto the seat plate and press it into place.
2. Remove the back upholstery.
3. Slip three mounting clamps for the back of the contour seat onto the right and left of the
frame, respectively.
4. Put the seat back in place and mount it with six Allen head screws.
1 Frame for back rest
2 Back of the contour seat
3 Mounting clamps (6)
