69
❒ Allen wrench, size 3
1. Attach the rear view mirror to the track on the control panel holder.
2. Individually adjust it to user requirements by turning it manually.
Attendant controls are delivered as an installation kit. On the B500/B500-S power wheelchair
with the standard or contour seat, they are attached to cross tube on the back rest. Two bore
holes are provided for this purpose on the left and right of the back tube, respectively.
❒ Allen wrench, size 4
1. Hold the bracket for the attendant controls against the back tube.
2. Attach with two Allen head screws.
On the B500/B500-S power wheelchair with the Recaro® seat, the attendant controls are at-
tached to the headrest.
❒ Allen wrench, size 3
❒ Open-end or combination wrench, size 10
