Otto B500 - 7.3.6 Speed Mode

79
 
The Speed Mode menu allows the therapist or dealer to determine the number of modes avail-
able for selection by the operator and to establish the maximum speed for each mode.
It is important to note that the maximum speed setting acts like a speed limit potentiometer. It
adjusts the driving and steering speed and responses as a linear interpolation of the minimum
and maximum parameter settings in the proles (the parameter settings are found in the Drive
and Steer menus). The speed, acceleration and deceleration are all affected by the speed mode.

Prole 1 is active and has the following settings:
– Fwd Max Speed = 100 %
– Fwd Min Speed = 20 %
– Turn Accel High Speed = 80 %
– Turn Accel Low Speed = 60 %
– Selected Speed Mode = 50 %
The resulting driving and steering characteristics are as follows:
Forward speed = (100 % – 20 %) * 50 % + 20 % = 60 %
Steering acceleration = (80 % – 60 %) * 50 % + 60 % = 70 %
 


Number of Modes 1 – 5 Number of speed modes the driver can access.
Speed 1 0 – 100 % Speed limit for Speed Mode 1.
Speed 2 0 – 100 % Speed limit for Speed Mode 2.
Speed 3 0 – 100 % Speed limit for Speed Mode 3.
Speed 4 0 – 100 % Speed limit for Speed Mode 4.
Speed 5 0 – 100 % Speed limit for Speed Mode 5.
Speed 6 0 – 100 % Speed limit for Speed Mode 6.
Speed 7 0 – 100 % Speed limit for Speed Mode 7.
Speed 8 0 – 100 % Speed limit for Speed Mode 8.
Speed 9 0 – 100 % Speed limit for Speed Mode 9.
Attendant Speed
1
0 – 100 % Speed limit for attendant control, Speed Mode 1.
Attendant Speed
2
0 – 100 % Speed limit for attendant control, Speed Mode 2.
 
