1. After completing the preparations, the battery case can simply be removed and replaced if
required.
Properly reassemble all components upon completion of the work.
NOTICE
Ensure correct polarity is used when connecting the batteries.
❒ Remove the battery cover (see Section 6.3.1).
❒ Remove the fuse (see Section 6.2).
❒ Disconnect and remove the battery (see Section 6.3.3).
❒ Allen wrench, size 3
❒ Open-end or combination wrench, size 11
1. Remove all cable ties from the battery cable.
2. Disconnect the old main battery cable from the controller (for connections on the controller,
see Figure 8).
3. Insert the new battery cable through the hole at the front of the battery case.
4. Reinstall and reconnect the batteries.
5. Connect the battery cable at the proper location on the battery.
6. Loosen the four Allen head screws on the two-part protective cover on the controller and re-
move the protective cover.
7. Connect the new battery cable to the controller and attach it with cable ties as before.
Properly reassemble all components upon completion of the work.
(Only for Lead-Acid Batteries)
HINWEIS
Ensure correct polarity is used when connecting the batteries.
❒ Pull out the battery case (see Section 6.3.1).
❒ Pull out the fuse (see Section 6.2).
❒ Remove the battery (see Section 6.3.3).
