44
The rear lights are attached to the back of the drive unit sustainer with two holders.
❒ Allen wrench, size 5
1. Insert oval head screws through the drive unit sustainer from the inside to the outside.
2. Secure the oval head screws with two lock nuts.
❒ Allen wrench, size 3
❒ Flat screwdriver, narrow
1. Fold the halogen lamp with cover forward by pressing the black locking lever on the bottom
of the lamp.
2. Pull the retaining ring back.
3. Pull the halogen lamp back, remove it and replace it if required.
Properly reassemble all components upon completion of the work.
During installation, ensure that the notch on the lamp socket is positioned correctly
and engages.
