54
1. Drill a Ø 6 mm hole in the middle of the cross brace.
2. Insert the screw to mount the adapter.
3. Insert the abductor holder into the adapter.
4. Screw the abductor in place at the desired location.
(Option)
The headrest holder is attached to the back frame.
❒ Allen wrench, size 3
❒ Open-end or combination wrench, size 10
1. Attach the holder to the top of the back tube with two screws.
A round back tube requires an adapter plate in order to compensate for the curvature (ordered
separately). The holes are predrilled.
