Off/Seat 0, 1 0 = Multi-Function Input 2 is ignored.
1 = Inhibit and / or speed limit active, depending whether the input
is high or low (see next parameter).
Active Low On/Off
When set to On, the inhibit and speed limit are active when the
contact is closed (set to B-). When set to Off, these functions are
active when the contact is open.
Act 1 Dir + Inhibit On/Off Set to On, actuator 1 is locked in the positive direction.
Act 1 Dir – Inhibit On/Off Set to On, actuator 1 is locked in the negative direction.
Act 2 Dir + Inhibit On/Off Set to On, actuator 2 is locked in the positive direction.
Act 2 Di r– Inhibit On/Off Set to On, actuator 2 is locked in the negative direction.
Speed Limit 0-100 % Sets the speed limit when input 2 is active.
The parameters in the “Multi-Function Input 3” menu can be used for a swivel seat (= 1) and a
related speed limit. Alternatively, they can be used for a speed limit activated by a switch. Multi-
Function Input 3 is on pin 7 of the 14-pin control unit plug.
Off/Swvl/Seat 0 – 2 0 = Multi-Function Input 3 is ignored.
1 = Offers a swivel seat function. This is used for wheelchairs that
have a swivelling seat in order to switch between front-wheel drive
and rear-wheel drive. Set to 1, the prole changes from Prole 1 to
Prole 2 when input 3 is active (see next parameter). In addition,
the motors are switched and the direction of rotation is reversed.
The MyChair setting is ignored in the swivel seat function.
2 = Sets the speed limit described below when input 3 is active.
Active Low On/Off
When set to On, the swivel seat and speed limit are active when
the contact is closed (set to B-). When set to Off, these functions
are active when the contact is open.
Act 1 Dir + Inhibit On/Off Set to On, actuator 1 is locked in the positive direction.
Act 1 Dir – Inhibit On/Off Set to On, actuator 1 is locked in the negative direction.
Act 2 Dir + Inhibit On/Off Set to On, actuator 2 is locked in the positive direction.
Act 2 Dir – Inhibit On/Off Set to On, actuator 2 is locked in the negative direction.
Speed Limit 0 – 100 % Sets the speed limit when input 3 is active.
