24
❒ Ring or open-end wrench, size 11
1. Route the battery vent hose through the hole at the rear of the battery case.
2. Insert the battery.
3. Properly connect the vent hose to the battery.
Properly reassemble all components upon completion of the work.
6.4 Replacing the Controller
Ensure correct polarity is used when connecting the cables.
For information on connecting the controller, please see Section 7.2.
❒ Pull out the battery case (see Section 6.3.1).
❒ Pull out the fuse (see Section 6.2).
❒ Remove the batteries (see Section 6.3.3).
❒ Allen wrench, size 3
1. Remove the two-part protective cover (see Figure 8).
2. Disconnect all connections on the controller.
3. Loosen the two Allen head screws, remove the controller and replace if required.
Properly reassemble all components upon completion of the work.
