Panasonic EBL128 User Manual

Panasonic Eco Solutions Nordic AB
MEW01623 Rev: - EBL128 Operating Instructions V2.0.x
112
28.1 Calibration of supervised outputs (H5/A1)
Supervised (monitored) outputs
78
:
- The voltage outputs (S0-S1) in the control unit
- The voltage outputs (VO0-VO1) in the COM loop output unit 3364.
- The voltage outputs (Output 0-Output 1) on the Inputs and outputs
expansion board 4583
When all alarm devices (sounders, etc.) have been connected,
including required end-of-line devices
79
and when the SSD download
is ready, a calibration has to be done.
Function: If the actual value differs from the calibrated value ± a
small tolerance or if the calibrated value is outside the calibration
range
80
, a fault will be generated.
NOTE!
Each output's logic is programmable via EBLWin, i.e. normally low
(default) or normally high (24V) but during the calibration the outputs
will automatically be low, i.e. a normally high output will be low
during the calibration (a few seconds).
Action
Text in display
Comments
"Access"
According to chapter
"Access", see page 81.
Scroll to menu H5.
Service
ACCEPT? H5
"A"
Calibration of supervised outputs
ACCEPT? A1
"A"
To calibrate supervised outputs
press ACCEPT
"A"
Calibration in progress
Please wait......
"A"
Calibration is completed!
ACCEPT?
78
Supervised (monitored) outputs can via EBLWin be set to be not
supervised.
79
EBL128 outputs (S0-S1) and the exp. board 4583 outputs (Output 0-
Output 1): One end-of-line resistor (33K) in the last unit or one resistor
(33K) in up to five units.
3364 outputs (VO0-VO1): One end-of-line capacitor (470 nF) in the last
unit or one capacitor (470 nF) in up to five units.
80
4K7 – 50K and 470 – 5x470 nF respectively.
