32 Interlocking outputs and inputs
(H9)
32.1 Activated interlocking outputs/inputs
(H9/C1)
The way the date is presented can be different for different languages.
If there are no output / input activated, --- List is empty ---
will be shown.
Action
Text in display
Comments
"Access"
According to chapter
"Access", see page 81.
Scroll to menu H9.
Interlocking outputs and inputs
ACCEPT? H9
"A"
Activated interlocking outputs/inputs
ACCEPT? C1
"A"
Depending on activated
output and/or input, the
following will be
shown:
Output AA/PP activated at HH:MM
Information text (if progr.)
This is a list in which you
can scroll.
AA = interlocking
combination Area
PP = interlocking
combination Point (within
the area).
HH=Hour
MM=Minute
Press "Return" to menu
C1.
Output AA/PP act HH:MM, input act HH:MM
Information text (if progr.)
Input AA/PP activated at HH:MM
Information text (if progr.)
"Return"
Activated interlocking outputs/inputs
ACCEPT? C1
Scroll or press "Return" to
menu H9.
"Return"
Interlocking outputs and inputs
ACCEPT? H9
Scroll or press "Return".
