25.4 Disable all control, ventilation, exting or
interlocking outputs (H2/B4)
Outputs programmed as type Control (general), type Fire ventilation,
type Extinguishing system and type Interlocking can for the type
respectively be collectively disabled (all at the same time). Disabled
output means that even if the control expression (trigger condition)
for the output respectively is fulfilled (true), the output will not be
activated. Disabled outputs are shown in menu H4/U1.
The outputs will be disabled until re-enabled again (via H2/B8).
Action
Text in display
Comments
"Access"
According to chapter
"Access", see page 81.
Scroll to menu H2.
Disable or re-enable
ACCEPT? H2
"A"
Disable zone
ACCEPT? B1
Scroll to menu B4.
Disable all control, ventilation, exting
or interlocking outputs ACCEPT? B4
"A"
Disable type:0 0=Control 1=Ventilation
2=Exting 3=Interlocking ACCEPT?
For the type respectively
press:
"0"=control outputs
"1"=ventilation outputs
"2"=extinguishing outputs
"3"=interlocking outputs
Press "A" to accept.
LED "Disablements" (L8)
will light up.
"0", "1", "2" or "3"
"A"
Depending on the
chosen type the
following will be
shown:
All xxxxxxx outputs disabled
xxxxx=control, ventilation,
extinguishing or
interlocking
"A"
Disable type:0 0=Control 1=Ventilation
2=Exting 3=Interlocking ACCEPT?
If more disablements shall
be done, continue like
above. If not, press
"Return" to menu B4.
"Return"
Disable all control, ventilation, exting
or interlocking outputs ACCEPT? B4
Scroll or press "Return" to
menu H2.
"Return"
Disable or re-enable
ACCEPT? H2
Scroll or press "Return".
