8.2 What to Do If an Error Occurs
8-7
Error
code
Error name Description
Operation when an error
occurs and solution
41H
Table setting error The combination of tables is incorrect.
Each control operation does not
start. Correct the setting of the
parameter.
42H Operation pattern error
The set value of the operation pattern is
incorrect.
43H
Positioning acceleration
time error
The set value of the positioning acceleration
time is out of the range.
44H
Positioning deceleration
time error
The set value of the positioning deceleration
time is out of the range.
45H
Positioning target speed
error
The set value of the positioning target
speed is out of the range.
46H
Positioning movement
amount error
The set value of the positioning movement
amount is out of the range.
47H Dwell time error
The set value of the dwell time is out of the
range.
48H J point control setting error
The J-point control is set on the
interpolation axis table.
60H
Repeat operation dwell
time setting error
The dwell time of the E table which
performs repetitive operations is 0 ms.
Error code 41: Occurrence condition of table setting error
• The last table of the positioning setting tables is not the E point. (e.g. The P point, C point
and J point are set continuously.)
• The control method of the J-point control table is absolute.
• The tables whose control method is absolute are set repeatedly.
• The opposite pulse output directions (forward/reverse) are set on the consecutive tables of
P+E points.
• Axes to which the interpolation operation setting is made are selected for the F383
simultaneous start instruction.
