Panasonic Lumix S1R User Manual

6. Focus/Zoom
120
0 On the recording screen, you can rotate the focus ring to display the MF Assist
screen. If you have enlarged the picture by rotating the focus ring, the assist
screen will close approx. 10 seconds after the operation.
0 During MF, pressing [AF ON] will activate AF.
0 The recording distance reference mark is a mark
used to measure the focus distance.
Use this when taking pictures with MF or taking
close-up pictures.
0 Change the peaking sensitivity and the display method:
[] ¨ [ ] ¨ [Focus Peaking] (l 310)
0 Memorises the MF Assist position separately for vertical and horizontal
orientations:
[] ¨ [ ] ¨ [Focus Switching for Vert / Hor] (l 116)
0 You can change the display method of the magnified screen:
[] ¨ [ ] ¨ [MF Assist] (l 330)
0 Change the MF Guide display method:
[] ¨ [ ] ¨ [MF Guide] (l 330)
0 Disable focus ring operation:
[] ¨ [ ] ¨ [Focus Ring Lock] (l 330)
0 Set the movement of the MF Assist position to loop:
[] ¨ [ ] ¨ [Looped Focus Frame] (l 333)
0 The camera memorises the focus position when you turn it off:
[] ¨ [ ] ¨ [Lens Focus Resume] (l 348)
0 The amount of focus movement can be set:
[] ¨ [ ] ¨ [Focus Ring Control] (l 348)

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
