Panasonic Lumix S1R

1. Introduction
25
5
4
3
2
1
7
8
16
17
6
9
10
13
14
15
11
12
1
Dioptre adjustment dial (l 66)
2
Operation lock lever (l 65)
3 [(] (Playback) button (l 259)
4
Monitor lock lever (l 58)
5
Monitor (l 448)/
Touch screen (l 64)
6 Video rec. button (l 230)
7
[ ] (AF mode) button (l 92)
8
[AF ON] button (l 94)
9 Focus mode lever (l 92, 117)
10
Joystick (l 64)/
Fn buttons (l 278)
Centre: Fn8, 3: Fn9, 1: Fn10,
4:Fn11, 2: Fn12
11
[Q] button (l 71)
12
Cursor buttons (l 63)/
Fn buttons (l 278)
3: Fn13, 1: Fn14, 4: Fn15,
2: Fn16
13 Control dial (l 63)
14 [MENU/SET] button (l 63, 73)
15 [ ] (Cancel) button (l 75)
16 [ ] (Delete) button (l 269)
17 [DISP.] button (l 68)
0 If you press [ ], the following buttons light.
The lighting timing can be changed in [Illuminated Button] in the [Custom]
([Operation]) menu. (l 337)
–[(] button/[Q] button/[ ] button/[ ] button/[DISP.] button
