164

Setting Inspection Conditions

Chapter 4

Registering Inspection Results in Numerical

Calculation

(This is supported in Ver.1.30 or later.)

The detected coordinate and differential value of cells and judgement can be registered into Numerical

Calculation from the checker setting window. Although you can register them also in Numerical Calculation

setting window, information of many cells can be registered efficiently with less operation from the checker

setting window.

Data that can be registered into Numerical Calculation from Connecter (Gray Edge) setting window

• Pitch

• Pitch Judgement

• Distance Difference

• Distance Difference Judgement

• X coordinate 0

• Y coordinate 0

• Differential value 0

• X coordinate 1

• Y coordinate 1

• Differential value 1

The setting procedure is the same as Connector (Binary Window) and Connector (Gray Window). Refer to

page

149 for details.

Registering into Data R/W

(This is supported in Ver.1.30 or later.)

The detected pitch, distance difference, and judgement limits of cells and judgement can be registered into

Data R/W from the checker setting window. Although you can register them also in Data R/W setting window,

information of many cells can be registered efficiently with less operation from the checker setting window.

Data that can be registered into Data R/W from Connecter (Gray Edge) setting window

• Result No.: Cell No. of the first cell to register

• Maximum: Max. Judge. Pitch

• Minimum: Min. Judge. Pitch

• Max. Dist. Differ.: Max. Distance Difference

• Min. Dist. Differ.: Min. Distance Difference
