Panasonic PV500 - Operators and Functions

235
Setting Inspection Conditions
Chapter 4
INDEX
4.11.3 Operators and Functions
Operators
+
Addition
-
Subtraction
*
Multiplication
/
Division
If denominator becomes "0", the calculation will be terminated and an error signal
(ERROR1) will be output.
(, )
Parenthesis
Up to three parentheses can be used successionally. You cannot use four or
more of them successionally.
Correct: (((A+B)-C+D)+E), Wrong: ((((A+B)-C+D)+E)+F)
Arithmetical Function
MOD (S0, S1)
Remainder when S0 is divided by S1
e.g.) MOD (9,4) = 1
POW (S0, S1)
Value of S0 multiplied by S1.
e.g.) POW (3, 2) = 9
LOG10 (S)
Common logarithm of S
e.g.) LOG10 (100) = 2
SQRT (S)
Square root of S
e.g.) SQRT (144) = 12
ABS (S)
Absolute value of S
e.g.) ABS (-255) = 255
PI( )
Pi (fixed value)
PI ( )= 3.142
INT (S)
Integer portion of S
e.g.) INT (-1.8) = -1
ROUND (S)
Round S to a whole number
e.g.) ROUND (1.485) = 1
FLOOR (S)
Round S down to a whole number
e.g.) FLOOR (1.485) = 1
CEIL (S)
Round S up to a whole number
e.g.) CEIL (-1.3) = -1
Difference among INT, ROUND, FLOOR and CEIL
S
INT (S)
ROUND (S)
FLOOR (S)
CEIL (S)
1.5
1
2
1
2
1.4
1
1
1
2
-1.4
-1
-1
-2
-1
-1.5
-1
-2
-2
-1
Statistical Function
MAX(C,S)
Maximum value from S-number of results of numerical
calculation No.C
Example)
In the case of
CA000=10
CA001=5.8
CA002=3
MAX(0, 3) = 10
MIN(0, 3) = 3
AVE(0, 3) = 6.267
SUM (0, 3) = 18.8
SORT(0, 3, 1, 0)=3
The 0-th (smallest) value
of the ascendingly sorted
results of numerical
calculation No.0 to 2.
MIN(C,S)
Minimum value from S-number of results of numerical
calculation No.C
AVE(C,S)
Average of S-number of results of numerical
calculation No.C
SUM(C,S)
Sum of S-number of results of numerical calculation
No.C
SORT(C,S0,S1,S2)
S2th value when sorting S-number of numerical
calculation No.C in order of S1 condition
(0=descending, 1=ascending).
