Setting Inspection Conditions
4.5 Capturing an Image
This function can save an image processing of inspection object in the memory.
Specify the inspection area and conditions based on the image. The image is for setting criteria of an inspection.
Capture a base object maintaining the lighting condition to take an image.
1.
Press the F1 key and select “Delete” from the displayed menu.
2.
Select “Live” for "Memory/Live".
3.
Place an object beneath the camera.
4.
Press the TRIG key.
A test run is executed and an image is captured.
You can call up the images saved in PV500 or a SD memory card to set checkers and execute a test.
About how to save and read images, refer to Chapter 4.16, page 280.
