Panasonic PV500 - Overview of ENVIRONMENT

330
Environment Settings
Chapter 6
6.1 Overview of ENVIRONMENT
In ENVIRONMENT in SETUP menu, the following items can be set including inspection conditions except
checkers. The settings in ENVIRONMENT are the common settings for all Types.
System Settings
This menu sets the status of PV500 at startup and in the execution mode.
• Startup setting
Page 331
• Operation
- Operation when switching to SETUP menu
Page 332
- Inspection sequence and output timing of results and images
Page 334
- Operation on a template of Smart Matching
Page 125
• System Register
Page 337
Input/output
(Page 338)
This menu sets items on communication with external devices such as parallel I/O and serial port.
Camera
This menu sets camera type to use and the polarity of FLASH signal output from PV500.
• Camera
Page 58
• FLASH polarity
Page 59
Color
(page 340)
This menu sets display color of letters and background on the screen and transparence of dialogue window in
SETUP menu.
Password
This is the function to protect from operational errors. Inputting a password is required when switching from
RUN menu to SETUP menu. The function prevents changing the inspection conditions by mistake.
For the information of operation to switch to SETUP menu, refer to page 334.
Initialize
This menu initializes all settings under ENVIRONMENT menu.
