Panasonic PV500 - Registerable Items

297
Setting Inspection Conditions
Chapter 4
INDEX
4.18.3 Registerable Items
The data that can be registered in cells of Data R/W are listed below.
• “Yes” in the “Change” column indicates the value of the cell is modifiable from Data R/W sheet.
• The columns of Position Adjustment and Area Size Adjustment show that the item can be registered in
Data R/W or not, when they are used for the adjustments.
Items that can be registered in Data R/W
Statistics group
A number is indicated in "Statistics" column for statistics items. See below.
No.
Numeric Statistics
All Statistics
OK Statistics
NG Statistics
2
Statistics of checker results
If the checker is OK, calculates “All Statistics”
and “OK Statistics”. If the judgement is NG,
calculates “All Statistics” and “NG Statistics”.
Minimum
OK Judge. Min.
NG Judge. Min.
Maximum
OK Judge. Max.
NG Judge. Max.
Average
OK average
NG average
Range
OK Range
NG range
Variance
OK Variance
NG Variance
3
Judgment Statistics
If the checker is OK, calculates “All Statistics”
and “OK Statistics”. If the judgement is NG,
calculates “All Statistics” and “NG Statistics”.
When referring the statistics of
judgments(JDC/JRC) during in RUN mode,
the latest result is referred.
Scan Count
(Judgment
Count)
OK count
NG count
Checker
Position Adjustment (PAC)
Change
Statistics
Parameter
Base Checker Parameter No.0-3 *1)
Yes
No
Result
Judgement
No
3
Inspection time
No
2
Base Position X
No
2
Base Position Y
No
2
Base Position Theta
No
2
Adjustment Amount X
No
2
Adjustment Amount Y
No
2
Adjustment Amount Theta
No
2
Detect Position X
No
2
Detect Position Y
No
2
Detect Position Theta
No
2
Base Judgement Results
No
3
Base Inspection Time
No
2
Base X-Coordinate
No
2
Base Y-Coordinate
No
2
Base Proj. X Axis
No
2
Base Proj. Y Axis
No
2
Area Size Adjustment (AUC)
Change
Statistics
Parameter *2)
Yes
No
Result
Judgement
No
3
Inspection time
No
2
X coordinate
No
2
Y coordinate
No
2
Proj. X
No
2
Proj. Y
No
2
*1) Applies to the items that “Position Adjustment - Base checker” column is “Yes” for each checker
*2) Applies to the items that “Area Size Adjustment” column is “Yes” for each checker
