Panasonic PV500 - General Specification

436
Specifications and List of Product Numbers
Chapter 11
11.1 General Specification
PV500
2-Camera type
4-Camera type
CPU
32-bit RISC CPU & DSP
Number of camera connections
Up to 2
Up to 4
Processing resolution
Hor. 640 x Ver. 480 pixels (Quad-speed digital camera, Ultra compact
digital camera, 0.3-Mega Compact Gray Camera*1)
Hor. 1600 x Ver. 1200 pixels (2-Mega-pixel digital camera)
Processing function
Gray Scale: 8 bits, 256 gray scale (Binary: 8 groups/product type and
memory)
Partial imaging: Up to 2 areas can be set.
Interface
Serial
RS-232C x 1
Parallel input
I/O terminal (Phoenix): Input 14 points,
I/O connector (MIL connector type): Input 32 points.
24V DC, Bi-directional photo coupler
Parallel output
I/O terminal (Phoenix): Output 15 points,
I/O connector (MIL connector type): Output 32 points
NPN output type (N at the end of the product number): 5 to 24 V DC,
Photo coupler output
PNP output type (P at the end of the product number): 5 to 24V DC,
Photo Mos output
USB
For USB2.0, AB type (for PVWIN only)
Ethernet
Ethernet Port x 1
Media: 10-BASE-T / 100BASE-TX / 1000BASE-T, protocol: TCP/IP
(General purpose communication), UDP/IP (PLC communication))
Memory card
SD memory card slot x1
Monitor output
1ch: XGA (1024 X 768) output
Setting
1 ch: For the dedicated keypad
Rating
Voltage
24 V DC Operating voltage range: 21.6 to 26.4 V DC (with ripples)
Power
Consumption
1.5 A or less
2.0 A or less
Environmental
resistance
Operating
temperature
range
0 to +45 °C (without icing and
dew condensation)
0 to +40 °C (without icing and
dew condensation)
Operating
humidity range
35 to 85% RH (without icing and dew condensation at 25°C)
Noise resistance
1000 V pulse width 50 ns/1 µs (a noise simulator was used.)
Vibration
resistance
10 to 55 Hz, one sweep per minute, amplitude 0.75 mm, 30 minutes
each in X/Y/Z direction
Shock resistance
196m/ s
2
, 5 times each in X, Y and Z directions
Insulation
resistance (initial)
100 MΩ or more (500 V DC by insulation resistance tester)*2
Input terminals and output terminals - Power terminal and functional
earth
Input terminals and output terminals - Non-electrifiable metal part
Power terminal - Non-electrifiable metal part
Voltage
resistance (initial)
500 V AC / minute (600 V AC / second), cutoff current 10 mA *2
Input terminals and output terminals - Power terminal and functional
earth
Input terminals and output terminals - Non-electrifiable metal part
Power terminal - Non-electrifiable metal part
Battery life
Approx. 10 years (at 25°C)
Weight
Approx. 1600 g
