233
Setting Inspection Conditions
Chapter 4
INDEX
Item
Result
No.
Result Type
Statistics
type
Output Value, etc
Individual Result:
3/3 page
0-2999
Individual Judgement (IJUDGE)
1
OK=1, NG=0
Measurement value (LEN)
2
X 0 (X0)
2
Y 0 (Y0)
2
Differential 0 (D0)
2
0 -255
X 1 (X1)
2
Data of the edges detected
with the condition 1 when
selecting Width for Detect
Mode
Y 1 (Y1)
2
Differential 1 (D1)
2
Judgement Code (STAT)
2
0-4 *1)
*1)
0:
Cell that detected edges and Individual Judgement NG cell
1:
Cell that detected edges and Individual Judgement OK cell
2:
Cell that detected edges and denoising
3:
Cell that detected no edge
4:
Masked cell
Geometry Calculation
Detected result data varies depending on the type of geometry calculation. Refer to Geometry Calculation:
page 211 for details.
Item
Result
No.
Result Type
Statistics
type
Output Value, etc
Geometry
Calculation (GGC)
No.0-999
Result: 1/2 page
---
X coordinate (X)
2
Y coordinate (Y)
2
Standard Deviation (STD)
2
Angle (ANG)
2
Line Parameter A (LINEA)
2
Line Parameter B (LINEB)
2
Line Parameter C (LINEC)
2
Distance (DIST)
2
Intersecting Angle (CANG)
2
0 - 360
Radius (R)
2
Major Axis (LA)
2
Minor Axis (SA)
2
Inspection Time (TIME)
2
Judgement: 2/2
page
Judgement (JUDGE)
1
OK=1, NG=0
X Judgement (XJUDGE)
1
Y Judgement (YJUDGE)
1
Standard Deviation Judgement
(SJUDGE)
1
Angle Judgement (AJUDGE)
1
Distance Judgement (DJUDGE)
1
Intersecting Angle Judgement
(CAJUDGE)
1
Radius Judgement (RJUDGE)
1
Major Axis Judgement (LAJUDGE)
1
Minor Axis Judgement (SAJUDGE)
1
