254
Setting Inspection Conditions
Chapter 4
List of Menu Options
Character/Figure Drawing No.000 to 999*
└
┬
Comment
├
Camera
├
Color by Judgement
├
Color (OK Color)
├
NG Color
└
No.0 - 9
─────
─
┬
Line
┬
Start XY, End XY
│
│
├
│
Line Display
─
Segment / Half line 0 / Half line 1 /
Wall-to-wall
│ └
Arrowhe
ad
─
None / Start / End / Both
│
├
Cross
┬
IP XY
│ ├
Cross
Display
─
Normal / Wall-to-wall
│ └
Length
─
3 - 999
│
├
Rectangle
┬
Start XY, End XY
│ └
Solid
│
├
│
Slanted
rectangle
┬
└
Center XY, Width, Height, Angle
Solid
│
├
Ellipse
┬
Center XY, Width, Height, Start Angle, End Angle, Angle
│ ├
Solid
│ └
Arrowhea
d
─
None / Start / End / Both
│
└
Character
┬
Display Character
├
Coordinate XY
├
Character Size
─
22 - 440
├
│
│
│
│
Display Base
─
Top Left / Top Center / Top
Right / Left Center / Center /
Right Center / Bottom Left /
Bottom Center / Bottom Right
├
Offset Unit
─
Characters / Pixel
├
Offset X
├
Offset Y
├
│
Judgement
Display
─
1 0 E / OK NG ER
├
Digit Count
─
1 - 15
├
Decimal Digit
─
0 - 3
└
Alignment
─
Left / Center / Right
* When the number of blocks is 10.
