439
Chapter 11
Specifications and List of Product Numbers
INDEX
XGA Monitor: ANPVM11021
General Specification
Rated power
Power supply voltage
24 V DC Operating voltage range: 21.6 to 26.4 V
DC
Power Consumption
0.5 A (Max. 1 A)
Environmental
resistance
Operating ambient temperature
0 to +45 °C
Operating ambient humidity
35 to 85 %RH (without dew condensation at 25°C)
Power noise
1,000 V (P-P) or more, pulse width 50 ns, 1 µs between
power terminals (a noise simulator was used.)
Static electricity noise
4000 V or more
Vibration resistance
10 to 55 Hz (1 sweep per minute), amplitude 0.75 mm,
30 minutes each in X, Y and Z directions
Shock resistance
196 m/s
2
, 3 times each in X, Y and Z direction
Weight
Approx. 1.4kg
Specification for Display Area
Display element
10.4-inch TFT liquid crystal
Number of pixels
1024(H) x 768(V) pixels
Display color
16,777,216 colors
Effective display size
210.4(H) x 157.8(V)
Service life of backlight
Average: 50,000 hours
Input Signal
Picture signal
Analog RGB
Synchronizing signal
Horizontal/vertical synchronizing signal
Horizontal operation frequency
48.36 kHz* (Number of all pixels: 1024)
Vertical operation frequency
60 Hz* (Number of all lines: 768)
Dot clock
65 MHz
Interface
Analog RGB input, Mini-D-SUB connector 15 pins
(female)
Screen adjustment
Brightness, display width, vertical and horizontal
positions, flicker, gain(R,G,B)
*The specified signals should be used for the monitor. Failure to do so may result in no screen display and noise
occurrence on the screen.
