43
Basic Operation
Chapter 3
INDEX
Selecting an Image Type
Select how display the image captured by a camera on the screen window.
SETUP Menu
Camera No.
┬
Memory
┬
Gray
┬
Preprocess: No
│
│
└
Preprocess A-E
─
Step: 1st – 10th
│
│
│
└
Binary (Slice Level
A-Z)
┬
Preprocess: No
│
└
Preprocess: A-E
─
Step: 1st – 10th
│
└
Live
─
Same as “Memory”
RUN Menu
Camera No.
┬
Memory
┬
Gray
┬
Preprocess: No
│
│
└
Preprocess A-E
│
│
│
└
Binary (Slice Level
A-Z)
┬
Preprocess: No
│
└
Preprocess A-E
│
├
Live
─
Same as “Memory”
│
└
NG Image
┬
Latest
┐
│
Previous
├
Same as “Memory”
└
Before the Previous
┘
Options
Memory/Live
• Memory:
An image stored in a memory for inspection. The image does not
change even if you cover the lens or uncover it.
If you want to run a test using the image memory of PV500 or
images in a SD card in SETUP menu, switch to Memory.
• Live:
An image changes in real-time. When you cover the lens with
your hand, a captured image will be darker, while it will be lighter
when you uncover it.
Gray/Binary
• Gray scale:
A gray image in 256 gray levels captured by a camera.
• Binary:
A binarized image in black and white based on a gray image.
For details, refer to Chapter 4.6.1 “
Binarizing an Image (Slice
Level)”, page 80.
NG Image
(only for RUN
Menu)
Displays a memory image when the result of a judgement formula registered as Total
Judgement is "NG". Select from "Latest", "Previous", and "Before the Previous".
• Latest:
Displays an image of the latest NG total judgement.
• Previous:
Displays an image of the previous NG total judgement.
• Before the
Previous:
Displays an image of before the previous NG total judgement.
Preprocess
A preprocessed image can be displayed when using the function.
• No:
Displays an image before preprocess.
• A to E:
To select a Preprocess Group.
