456
Appendix
String function
Numerical Calculation
Judge. Meaning of function
Statistics
Result
GGCnnn_XJUDGE
@ (Type1)
Yes
Yes
Geometry Calcu.
X Judgement
GGCnnn_Y
@ (Type2)
Yes
Geometry Calcu.
Y
GGCnnn_YJUDGE
@ (Type1)
Yes
Yes
Geometry Calcu.
Y Judgement
GT(
Yes
Returns "1" when (the first term in
parentheses) is greater than (the second
term), otherwise "0".
GWCnnn_AVE
@ (Type2)
Yes
Gray Window
Gray Average
GWCnnn_JUDGE
@ (Type1)
Yes
Yes
Gray Window
Judgement
GWCnnn_TIME
@ (Type2)
Yes
Gray Window
Inspection Time
INT(
Yes
Integer portion of a value in parentheses
JDCnnn_JUDGE
@ (Type1)
Yes
Yes
Judgement
(External output)
Judgement
JRCnnn_JUDGE
@ (Type1)
Yes
Yes
Judgement
(Internal)
Judgement
LE(
Yes
Returns "1" when (the first term in
parentheses) is less than or equal to (the
second term), otherwise "0".
LICnnn_DCOUNT
@ (Type2)
Yes
Line
No. of pixels
LICnnn_DJUDGE
@ (Type1)
Yes
Yes
Line
Pixel Judgement
LICnnn_JUDGE
@ (Type1)
Yes
Yes
Line
Judgement
LICnnn_LCOUNT
@ (Type2)
Yes
Line
No. of objects
LICnnn_LJUDGE
@ (Type1)
Yes
Yes
Line
Object Judgement
LICnnn_TIME
@ (Type2)
Yes
Line
Inspection Time
LINESA(
Yes
Element a of a regression line expression in
least squares calculated by multiple
coordinate values specified with three
values in parentheses
LINESB(
Yes
Element b of a regression line expression in
least squares calculated by multiple
coordinate values specified with three
values in parentheses
LINESC(
Yes
Element c of a regression line expression in
least squares calculated by multiple
coordinate values specified with three
values in parentheses
LOG10(
Yes
Common logarithm of a value in
parentheses
LT(
Yes
Returns "1" when (the first term in
parentheses) is less than (the second
term), otherwise "0".
MAX(
Yes
Maximum value of the calculation results
for the number specified by the second
term in parentheses from the Numerical
Calculation No. specified by the first term.
MIDDLEX(
Yes
Coordinate X of the median of two pairs of
coordinates specified with four values in
parentheses.
MIDDLEY(
Yes
Coordinate Y of the median of two pairs of
coordinates specified with four values in
parentheses.
MIN(
Yes
Minimum value of the calculation results for
the number specified by the second term in
parentheses from the Numerical
Calculation No. specified by the first term.
MOD(
Yes
Remainder when (the first term in
parentheses) is divided by (the second
term)
NE(
Yes
Returns "1" when (the first term in
parentheses) is not equal to (the second
term), otherwise "0".
