458
Appendix
String function
Numerical Calculation
Judge. Meaning of function
Statistics
Result
RTOPYC(c, Xr, Yr)
Yes
Y coordinate of the coordinate in pixels
converted from the real value specified by
the second and third terms of the camera
specified by the first term in parentheses.
SECnnn_AMAX
@ (Type2)
Yes
Smart Edge (Circle)
Max. Angle
SECnnn_AMIN
@ (Type2)
Yes
Smart Edge (Circle)
Min. Angle
SECnnn_CELL
@ (Type2)
Yes
Smart Edge (Circle)
No. of Cells
SECnnn_CIR0
@ (Type2)
Yes
Smart Edge (Circle)
Circularity 0
SECnnn_CIR1
@ (Type2)
Yes
Smart Edge (Circle)
Circularity 1
SECnnn_CJUDGE
@ (Type1)
Yes
Yes
Smart Edge (Circle)
Circularity
Judgement
SECnnn_CX0
@ (Type2)
Yes
Smart Edge (Circle)
Center X 0
SECnnn_CX1
@ (Type2)
Yes
Smart Edge (Circle)
Center X 1
SECnnn_CY0
@ (Type2)
Yes
Smart Edge (Circle)
Center Y 0
SECnnn_CY1
@ (Type2)
Yes
Smart Edge (Circle)
Center Y 1
SECnnn_D0.mmmm
@ (Type2)
Yes
Smart Edge (Circle)
Differential 0
SECnnn_D1.mmmm
@ (Type2)
Yes
Smart Edge (Circle)
Differential 1
SECnnn_DEV.mmmm
@ (Type2)
Yes
Smart Edge (Circle)
Deviation
SECnnn_FCNT
@ (Type2)
Yes
Smart Edge (Circle)
Used Edge Count
SECnnn_IJUDGE.mmmm
@ (Type1)
Yes
Yes
Smart Edge (Circle)
Individual
Judgement
SECnnn_JUDGE
@ (Type1)
Yes
Yes
Smart Edge (Circle)
Judgement
SECnnn_LAVE
@ (Type2)
Yes
Smart Edge (Circle)
Average
SECnnn_LEN.mmmm
@ (Type2)
Yes
Smart Edge (Circle)
Measurement
SECnnn_LJUDGE
@ (Type1)
Yes
Yes
Smart Edge (Circle)
Measurement
Judgement
SECnnn_LMAX
@ (Type2)
Yes
Smart Edge (Circle)
Maximum
SECnnn_LMIN
@ (Type2)
Yes
Smart Edge (Circle)
Minimum
SECnnn_NCNT
@ (Type2)
Yes
Smart Edge (Circle)
Unused Edge Count
SECnnn_NJUDGE
@ (Type1)
Yes
Yes
Smart Edge (Circle)
Unused Edge Count
Judgement
SECnnn_R0
@ (Type2)
Yes
Smart Edge (Circle)
Radius 0
SECnnn_R1
@ (Type2)
Yes
Smart Edge (Circle)
Radius 1
SECnnn_SJUDGE
@ (Type1)
Yes
Yes
Smart Edge (Circle)
Standard Devation
Judgement
SECnnn_STAT.mmmm
@ (Type2)
Yes
Smart Edge (Circle)
Judgement Code
SECnnn_STD
@ (Type2)
Yes
Smart Edge (Circle)
Standard Deviation
SECnnn_TIME
@ (Type2)
Yes
Smart Edge (Circle)
Inspection Time
SECnnn_X0.mmmm
@ (Type2)
Yes
Smart Edge (Circle)
X 0
SECnnn_X1.mmmm
@ (Type2)
Yes
Smart Edge (Circle)
X 1
SECnnn_Y0.mmmm
@ (Type2)
Yes
Smart Edge (Circle)
Y 0
SECnnn_Y1.mmmm
@ (Type2)
Yes
Smart Edge (Circle)
Y 1
SELnnn_ANG0
@ (Type2)
Yes
Smart Edge (Line)
Line 0 Angle
SELnnn_ANG1
@ (Type2)
Yes
Smart Edge (Line)
Line1 Angle
SELnnn_CELL
@ (Type2)
Yes
Smart Edge (Line)
No. of Cells
SELnnn_D0.mmmm
@ (Type2)
Yes
Smart Edge (Line)
Differential 0
SELnnn_D1.mmmm
@ (Type2)
Yes
Smart Edge (Line)
Differential 1
SELnnn_EA0
@ (Type2)
Yes
Smart Edge (Line)
Line0 Element a
SELnnn_EA1
@ (Type2)
Yes
Smart Edge (Line)
Line1 Element a
SELnnn_EB0
@ (Type2)
Yes
Smart Edge (Line)
Line0 Element b
SELnnn_EB1
@ (Type2)
Yes
Smart Edge (Line)
Line1 Element b
SELnnn_EC0
@ (Type2)
Yes
Smart Edge (Line)
Line0 Element c
SELnnn_EC1
@ (Type2)
Yes
Smart Edge (Line)
Line1 Element c
SELnnn_EX0
@ (Type2)
Yes
Smart Edge (Line)
Line 0 End
Coordinate X
SELnnn_EX1
@ (Type2)
Yes
Smart Edge (Line)
Line 1 End
Coordinate X
